Version: 24.12
In the Shortcuts settings, you can define which combination of keys you'd like to use as a shortcut for executing actions in Solibri. Custom keyboard shortcuts allow you to create the shortcuts based on your native language and language-specific keyboard, which makes it easier to use and remember them. You can freely assign a custom keyboard shortcut for actions, except for universal standard actions, or leave them empty. You can also download and share the shortcuts as a file. Please note that currently, it's not possible to customize mouse controls.
Note
The settings for custom keyboard shortcuts are available in Solibri v24.12.0 and newer. For keyboard shortcuts and mouse controls in older versions of Solibri, see here.
The article covers the following topics:
You can customize the keyboard shortcut for each action that currently has a default shortcut given by Solibri or has no currently assigned keyboard shortcut. To assign a keyboard shortcut:
-
Click on the respective keyboard shortcut field in File > Settings > Shortcuts…:
-
A dialog opens. Enter a key combination for the shortcut. You can apply a maximum of four keys to one shortcut.
-
When a valid shortcut is pressed, the dialog closes automatically. The keyboard shortcut is now assigned.
-
To make the new shortcut(s) applicable, click OK in the Shortcuts Settings.
When the keyboard shortcut has been applied, it's possible to remove it or restore it to default:
-
To remove the shortcut, right-click the shortcut field and select Remove. Removing an unnecessary default shortcut enables you to use it for another, more used action.
-
To restore the shortcut to its default state, click. If no default shortcut exists, the shortcut will be restored to an empty state. If the default shortcut to be restored has been assigned to another function, you'll be asked if you want to remove it from that function and use it in the current one.
-
To restore all shortcuts to default, click Restore Default Settings.
Important
Duplicate shortcuts: No duplicate shortcuts can exist, even if the shortcuts would apply to different views. All the keyboard shortcuts need to be unique.
Important
Reassigning shortcuts: If the shortcut you added had already been assigned to another shortcut, a Reassign button will appear. There’s an explanatory text that indicates to which functionality the shortcut has already been assigned to. To reassign the shortcut, click Reassign. You'll get a message saying that the shortcut is now used for the new functionality and removed from the previous functionality
You can save and export the currently assigned shortcuts as a .shortcuts file by clicking Save As. The file is editable.
You can import a .shortcuts file (one file at a time) by clicking Import File:
The imported shortcuts will override the shortcuts you've previously assigned. When importing the file, you'll get a warning that the current shortcuts will be overridden, and an option to proceed or not.
Important
To prevent invalid input, we strongly recommend that you don't edit the file after exporting it. Editing the file may result in errors. Note that if your shortcuts don't work correctly, this may be because you have invalid data in the file.
The General Shortcuts are applicable globally in the Solibri UI. They include universal standard actions that can only be viewed, not edited. The layout shortcuts are related to layouts in Solibri, and the Selection Basket shortcuts are related to the Selection Basket tools.
Table 41. General
|
Functionality |
Keyboard Shortcut |
|---|---|
|
Undo |
Ctrl/Cmd + Z |
|
Redo |
Ctrl/Cmd + Y |
|
Cut |
Ctrl/Cmd + X |
|
Copy |
Ctrl/Cmd + C |
|
Paste |
Ctrl/Cmd + V |
|
Search |
Ctrl/Cmd + F |
|
Focus |
TAB |
|
Save Model |
Ctrl/Cmd + S |
|
Cancel Action |
Escape |
|
Select All |
Ctrl/Cmd + A |
|
Go up |
Page Up/MacOS: Fn + Arrow up |
|
Go down |
Page Down/MacOS: Fn + Arrow down |
Table 42. Layout Shortcuts
|
Functionality |
Keyboard Shortcut |
|---|---|
|
Go to Layout 1 |
F1 |
|
Go to Layout 2 |
F2 |
|
Go to Layout 3 |
F3 |
|
Go to Layout 4 |
F4 |
|
Go to Layout 5 |
F5 |
|
Go to Layout 6 |
F6 |
|
Go to Layout 7 |
F7 |
|
Go to Layout 8 |
F8 |
|
Go to Layout 9 |
F9 |
|
Go to Layout 10 |
F10 |
|
Go to Layout 11 |
F11 |
|
Go to Ruleset Manager (and back) |
F12 |
Table 43. Selection Basket Shortcuts
|
Functionality |
Keyboard Shortcut |
Alternative |
|---|---|---|
|
Empty Selection Basket |
Ctrl/Cmd + Shift + Delete |
Ctrl/Cmd + Shift + Backspace |
*no default keyboard shortcuts assigned
The 3D tools shortcuts are related to the visualization tools.
Table 44. 3D Tools Shortcuts
|
Functionality |
Keyboard Shortcut |
|---|---|
|
Info tool |
5 |
|
Select tool |
6 |
|
Hide tool |
7 |
|
Markup tool |
8 |
|
Dimension tool |
9 |
|
Sectioning tool |
0 |
|
Change camera projection |
Ctrl/Cmd + Shift + O |
Table 45. Info Tool Shortcuts
|
Functionality |
Mouse Controls |
|---|---|
|
Show info |
Left mouse button |
|
Show part info |
Shift + left mouse button |
|
Start area selection |
Hold left mouse button down |
|
Show properties |
Double click left mouse button |
Table 46. Selection Tool Shortcuts
|
Functionality |
Mouse Controls |
|---|---|
|
Select |
Left mouse button |
|
Multi-select or unselect |
Ctrl/Cmd + left mouse button |
|
Select part |
Shift + left mouse button |
|
Start area selection |
Hold left mouse button down |
Table 47. Hide Component Tool Shortcuts
|
Functionality |
Mouse Controls |
|---|---|
|
Hide |
Left mouse button |
|
Hide part |
Shift + left mouse button |
|
Start Hide selection |
Hold left mouse button down |
Table 48. Markup Tool Shortcuts
|
Functionality |
Keyboard Shortcut |
Mouse Controls |
|---|---|---|
|
Add markup |
Left mouse button |
|
|
Delete markup |
Delete |
- |
|
Stop markup |
Esc |
- |
|
Start area selection |
Hold left mouse button down |
Table 49. Dimension Tool Shortcuts
|
Functionality |
Keyboard Shortcut |
Mouse Controls |
|---|---|---|
|
Add dimension |
Left mouse button |
|
|
Stop dimension |
Escape |
- |
|
Lock to component |
Ctrl/Cmd + left mouse button |
|
|
Lock to point |
Alt + left mouse button |
|
|
Start area selection |
Hold left mouse button down |
Table 50. Sectioning Tool Shortcuts
|
Functionality |
Keyboard Shortcut |
Mouse Controls |
|---|---|---|
|
Add section plane |
Left mouse button |
|
|
Move section plane |
PERIOD (left) COMMA (right) |
Shift + mouse wheel, Shift + hold left mouse button down |
|
Move section plane slower |
Ctrl/Cmd + PERIOD (left) Ctrl/Cmd + COMMA (right) |
Ctrl/Cmd + Shift + mouse wheel, Ctrl/Cmd + Shift + left mouse button down |
|
Select section plane |
Left mouse button |
|
|
Select next section plane |
Space |
- |
|
Flip section plane |
Backspace |
- |
|
Rotate section plane |
X |
- |
|
Rotate section plane to other direction |
Alt + X |
- |
|
Rotate section plane |
Y |
- |
|
Rotate section plane to other direction |
Alt + Y |
- |
|
Delete section plane |
Delete |
- |
|
Show/Hide section plane |
T |
- |
|
Start area selection |
Hold left mouse button down |
Table 51. Transparent Tool Shortcuts
|
Functionality |
Mouse Controls |
|---|---|
|
Set transparent |
Left mouse button |
|
Set part transparent |
Shift + left mouse button |
|
Start Transparent selection |
Hold left mouse button down |
Table 52. Show/Hide Tool Shortcuts
|
Functionality |
Keyboard Shortcut |
|---|---|
|
Show all |
Ctrl/Cmd + Shift + A |
|
Show only selected |
Ctrl/Cmd + Shift + S |
|
Show non-selected transparent |
Ctrl/Cmd + Shift + D |
|
Show/Hide space components |
Alt + S |
|
Show/Hide wall components |
Alt + W |
|
Show/Hide slab components |
Alt + L |
|
Show/Hide suspended ceiling components |
Alt + C |
|
Show/Hide roof components |
Alt + R |
|
Show/Hide door components |
Alt + D |
|
Show/Hide window components |
Alt + I |
|
Show/Hide beam components |
Alt + B |
|
Show/Hide column components |
Alt + O |
|
Show/Hide stair components |
Alt + T |
|
Show/Hide opening components |
Alt + P |
The 3D navigation shortcuts are related to the navigation tools.
Table 53. 3D Navigation Shortcuts
|
Functionality |
Keyboard Shortcut |
Mouse Controls |
|---|---|---|
|
Pan mode |
1 |
- |
|
Spin mode |
2 |
- |
|
Walk mode |
3 |
- |
|
Game mode |
4 |
- |
|
Bottom viewpoint |
Ctrl/Cmd + 0, Numpad 0 |
- |
|
Top Back Right viewpoint |
Ctrl/Cmd + 1, Numpad 1 |
- |
|
Back viewpoint |
Ctrl/Cmd + 2, Numpad 2 |
- |
|
Top Back Left viewpoint |
Ctrl/Cmd + 3, Numpad 3 |
- |
|
Right viewpoint |
Ctrl/Cmd + 4, Numpad 4 |
- |
|
Top viewpoint |
Ctrl/Cmd + 5, Numpad 5 |
- |
|
Left viewpoint |
Ctrl/Cmd + 6, Numpad 6 |
- |
|
Top Front Right viewpoint |
Ctrl/Cmd + 7, Numpad 7 |
- |
|
Front viewpoint |
Ctrl/Cmd + 8, Numpad 8 |
- |
|
Top Front Left viewpoint |
Ctrl/Cmd + 9, Numpad 9 |
- |
|
Elevate |
Page Up |
Ctrl/Cmd + Mouse wheel + Up |
|
Lower |
Page Down |
Ctrl/Cmd + Mouse wheel + Down |
|
Zoom out |
Minus |
Mouse wheel |
|
Zoom in |
Plus |
Mouse wheel |
|
Zoom extents |
Ctrl/Cmd + Quote |
- |
|
Zoom extents |
Home |
- |
|
Zoom selected |
Equals |
- |
|
Pan (move model to the left) |
Arrow left |
Left mouse button |
|
Pan (move model to the right) |
Arrow right |
Left mouse button |
|
Pan (move model up) |
Arrow up |
Left mouse button |
|
Pan (move model down) |
Arrow down |
Left mouse button |
|
Spin counter-clockwise |
Ctrl/Cmd + Arrow left |
Ctrl/Cmd + left mouse button |
|
Spin model clockwise |
Ctrl/Cmd + Arrow right |
Ctrl/Cmd + left mouse button |
|
Spin above center of the screen |
Ctrl/Cmd + Arrow up |
Ctrl/Cmd + left mouse button |
|
Spin below center of the screen |
Ctrl/Cmd + Arrow down |
Ctrl/Cmd + left mouse button |
|
Continuous spin |
Ctrl/Cmd + Alt + R |
- |
Table 54. Walk Navigation
|
Functionality |
Keyboard Shortcut |
Mouse Controls |
|---|---|---|
|
Walk to the left |
Arrow left, A |
Left mouse button |
|
Walk to the right |
Arrow right, D |
Left mouse button |
|
Walk forward |
Arrow up, W |
Left mouse button |
|
Walk backward |
Arrow down, S |
Left mouse button |
|
Free look to the left |
Alt + Arrow left |
Alt + left mouse button |
|
Free look to the right |
Alt + Arrow right |
Alt + left mouse button |
|
Free look to above |
Alt + Arrow up |
Alt + left mouse button |
|
Free look to below |
Alt + Arrow down |
Alt + left mouse button |
|
Walk faster |
Ctrl/Cmd down |
- |
|
Collision detection ON/OFF |
C |
- |
Table 55. Game Navigation
|
Functionality |
Keyboard Shortcut |
Mouse Controls |
|---|---|---|
|
Enter/Exit Game mode |
G |
Exit: left mouse button |
|
Enter/Exit Fly mode |
F |
- |
|
Move forward |
Arrow up, w |
- |
|
Move backward |
Arrow down, S |
- |
|
Strafe right |
Arrow right, D |
- |
|
Strafe left |
Arrow left, A |
- |
|
Walk faster |
Ctrl/Cmd down |
- |
|
Look around |
Move mouse |
|
|
Collision detection ON/OFF |
C |
- |
Table 56. Checking Results Shortcuts
|
Functionality |
Keyboard Shortcut |
|---|---|
|
Mark as 'Accepted' |
A |
|
Mark as 'Rejected' |
R |
|
Mark as 'Undefined' |
U |
|
Show slide |
S |
|
Add slide |
I |
|
Zoom in on result |
Z |
|
Add section box |
B |
Table 57. Presentation Shortcuts
|
Functionality |
Keyboard Shortcut |
|---|---|
|
Mark selected issues |
Ctrl/Cmd + J |
|
Unmark selected issues |
Ctrl/Cmd + Shift + J |
|
Add issue slide |
Ctrl/Cmd + I |
|
Add responsibilities |
Ctrl/Cmd + B |
|
Add label |
Ctrl/Cmd + L |
|
Add comment |
Ctrl/Cmd + K |
|
Add slide |
Ctrl/Cmd + M |
|
Update current slide |
Ctrl/Cmd + R |
|
Show slide |
Ctrl/Cmd + S |
|
Show in results |
Ctrl/Cmd + Shift + R |
